We use high quality European made components:
Contact us to see a full range of products available.
“The windows in an average home make up 8% of the total building, however they are accountable for up to 49% of the heat lost during Winter, and as much as 87% of the heat gained during Summer”
At Architech Windows we can help you make a vast improvement on these statistics with our uPVC windows and doors.
UPVC stands for Unplasticised Polyvinyl Chloride – rigid PVC. It is one of the most well researched and tested materials in terms of environmental credentials. uPVC is widely used in Europe, with more than 60% of homes in Germany using it.
UPVC windows are perfect for the Canberra climate where temperatures vary considerably throughout the year. The superior insulating qualities of uPVC windows make them an ideal, high performing and long lasting alternative to aluminium and timber framed windows.
U-value measures conductivity and is used as a benchmark to measure the window's thermal performance. The lower the U-value, the better the window performance. The U-value measures how well heat is transferred by the entire window – frame, sash and glass.
The lower the U-value, the more insulated the window unit. This means that the window will be more efficient at retaining interior heat in the winter and keeping heat out in the Summer.
A single glazed aluminium window typically has a u-value of 6.3+. Architech's double glazed uPVC windows can achieve a u-value of 1.9 or less.
Unlike aluminium, uPVC is non-conductive and has high insulative properties which means that window frames do not transfer heat, contributing to a more consistent internal temperature in a building.
UPVC windows are very durable with a long life span. They are UV resistant, non-corrosive, rust free and they do not rot or warp.
It consumes less energy to extrude uPVC frames than aluminium, there is a lower carbon footprint and uPVC frames are recyclable.
UPVC windows do not require painting or sealing. The frames are simply cleaned with water and mild detergent.
The joints for uPVC windows and doors are fusion welded and combined with a multi-chamber profile design means that they can cut down noise by up to 80%.
Our products are all double-glazed providing insulation benefits. We also offer various types of glass:
All of our double glazed units are filled with Argon gas which has 34% lower thermal conductivity than air.
Low-E glass deflects both long-wave and short-wave infrared while allowing visible light to enter. This improves insulation with minimal impact on visibility through the glass. Installing Low-E glass on the South and West facing windows in your home will ensure it remains cool in Summer and Warm during Winter.
We also offer a triple glazed option (up to 36mm) for the ultimate thermal and acoustic performance.
Instead of an aluminium spacer in between the glass, a warm edge spacer made of insulating composite material is used to reduce heat loss around the edge of the double glazed unit. This offers a higher surface temperature of the inside glass pane and less condensation at the edge of the window in high humidity environments such as the bathroom.
Laminated glass has a plastic glazing layer to provide greater impact resistance. Two panes of glass are joined together. We offer you the option of 6.38 mm or 8.76 mm thickness.
Laminated glass is great for acoustic insulation and filters UV rays to prevent deterioration of your carpet and furniture. It is shatter proof for extra security and safety as is commonly used in areas of the home such as bathrooms as these areas are most prone to people injuring themselves.
Installations are carried out by highly qualified carpenters who are experienced in uPVC double-glazed windows.
We use thermal imaging to audit every installation, ensuring no cold spots around the windows. We will provide you with a before and after thermal image report which visually demonstrated the thermal improvement to your home.
The image shows in this house during winter the surface temperature on our uPVC double glazed window is warmer than the internal wall.
The image reveals a cold spot on the corner of the window sash which indicates possible air leakage.
Contact us today or visit our office for more information and to view our range of products.
